| Brand Name: | FengQing |
| Model Number: | QVPA0425-00550W-B |
| MOQ: | 1 |
| Price: | Negotiated |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 80,000pcs/month |
Adopting a modular architecture design, it can be seamlessly integrated into handheld, vehicle-mounted, and fixed anti-drone platforms and existing systems. It is widely applicable to military, security, and critical infrastructure protection scenarios, providing system designers with a powerful, efficient, and versatile RF front-end solution that perfectly meets the needs of modern anti-drone applications.
(Strictly limited to legally authorized scope)
| Num | Output power/W | Frequency/MHz | Output power/dBm | Power flatness/dB | Efficiency/% | Size/mm |
|---|---|---|---|---|---|---|
| 1 | ≥50mW-50W | 400-500MHz | ≥17dBm-47dBm | ≤0.1dB | 50%-65% | 120*50*18.8 |
| 2 | ≥50mW-50W | 650-800MHz | ≥17dBm-47dBm | ≤0.1dB | 50%-65% | 120*50*18.8 |
| 3 | ≥50mW-50W | 800-1050MHz | ≥17dBm-47dBm | ≤0.1dB | 50%-65% | 120*50*18.8 |
| 4 | ≥50mW-50W | 1100-1300MHz | ≥17dBm-47dBm | ≤0.1dB | 50%-65% | 120*50*18.8 |
| 5 | ≥50mW-50W | 1300-1450MHz | ≥17dBm-47dBm | ≤0.1dB | 50%-65% | 120*50*18.8 |
| 6 | ≥50mW-50W | 1450-1600MHz | ≥17dBm-47dBm | ≤0.1dB | 50%-65% | 120*50*18.8 |
| 7 | ≥50mW-50W | 1550-1650MHz | ≥17dBm-47dBm | ≤0.1dB | 50%-65% | 120*50*18.8 |
| 8 | ≥50mW-50W | 2400-2500MHz | ≥17dBm-47dBm | ≤0.1dB | 50%-65% | 120*50*18.8 |
| Output Power/W | Model | Output Power/ MHz | Size/(mm) |
|---|---|---|---|
| ≥50mW–50W | QVPA0425-00550W-B | 400–2500 | 120*50*18.8 |
| ≥50mW–50W | QVPA0425-00550W-B2 | 400–2550 | 111*37*19.5 |
| Output Power / W | Model | Output Power/ MHz | Size/(mm) |
|---|---|---|---|
| ≥50mW–50W | QVPA0062-00550W-GN | 100–6200 | 111*37*19.5 |
| 112*38*19.5 | |||
| ≥50mW–70W | QVPA0062-00570W-GN | 100–6200 | 120*50*18.8 |
| 190*75*30 | |||
| 130*50*18.8 | |||
| ≥70W–100W | QVPA0060-70100W-GN | 100–6000 | 190*75*30 |
| 130*50*18.8 | |||
| 126*56*18.8 | |||
| 180*60*18.8 | |||
| ≥150W–200W | QVPA0059-150200W-GN | 400–5950 | 180*90*22.8 |
| 180*100*22.8 |
